Brine Storage Tank
3 x 3300 Imperial Gallon Closed Poly Tanks
- High Density, UV8 Stabilized Polyethylene
- Excellent chemical resistance
- Suitable for liquids with a maximum 1.5 Specific Gravity
- Self supporting
- Manufactured for industrial applications (including salt brine production and storage)
- NPT tank adapters on intake and discharge
- 3″ Bottom fill c/w check valve and all valve
- 3″ Bottom discharge valves
21″ hinged man-way- 3″ PVC “U” Vent
- Dimensions: 90″ Diameter x 162″ Overall Height (ea. tank)
Pumping System
- All plumbing included
- All plumbing to be corrosion resistant
- All valves and fittings are to be constructed of corrosion resistant materials.
2.0HP 220V electric motor (requires 20 amp circuit)- 120 USGPM centrifugal pump (suitable for re-circulation of material)
- Automatic shut-off for truck filler
- Automatic temperature sensitive, programmable recirculation
- All plumbing to be 2″
- Flow meter
- c/w reset batch counter and continuous counter
- Corrosion resistant
- Digital readout
Lockable pump house:
- Elevated for ease of use
- To contain flow meter, motor and pump, and all electrical
- Completely modular brine storage tank system for simple maintenance and reduced down-time
- All quick disconnect bulkhead fitting
- Strainer on intake side of pump
- 10-12 mesh screen
The brine storage tank is an excellent complement to the brine production system and to the automatic brine making system.
* Specifications subject to change for the improvement of the product.
