accurateWith the LaserLine GL1700, you can precisely locate start and stop points on walk-behind paint stripers for a more accurate, faster, and rugged model of paint striping laser guidance systems. The GL1700 system eliminates guess work and features a 5/8 mounting bracket with quick disconnect, enabling you to attach it to virtually any walk-behind machine in minutes.



Laser Specifications:

  • Wavelength: 510-532 nm
  • <2mrad
  • Laser Power: 4.75 mW
  • Class IIIa
  • OSHA compliant
  • Calculated operating life: 15000 hours MTBF



Operating temperature: -40 degrees F to 122 degrees F

Enclosure rating: outdoor dust and water rates to IP65

Vibration compliant per MIL-STD-810F method 5145 and truck assurance level 2, schedule E



Power source: 12 or 24 volt DC

Power draw: 0.1 of 1 amp at 12 vdc // 0.05 amp at 24 vdc

Reverse polarity and spike protected

Over temperature protection circuit

Automatic power control: keeps laser power stabilized through ambient temperature changes
